Products Description

Fiberglass Water Treatment Filter.High-flow filter cartridges are critical consumable elements used in high-capacity liquid filtration systems. Featuring a large-diameter design (typically 6 inches) and deep-bed filtration mechanisms with graded pore structures, these cartridges effectively remove suspended solids and particulate contaminants even under high flow velocities. Compared to conventional low-flow cartridges, high-flow designs require fewer units and less installation space to meet large-scale industrial water treatment demands, while significantly reducing manual replacement frequency and maintenance costs. Engineered for an optimal balance of high dirt-holding capacity, low initial pressure drop, and extended service life, they are the filtration medium of choice for modern large-scale water treatment systems.Fiberglass Water Treatment Filter.

High-flow filter cartridges

High-flow filter cartridges are deep filtration elements designed for high-flow-rate and large-volume liquid filtration. With a large-diameter design, a single cartridge can achieve flow rates of 30–100 m³/h.

Features

High flow capacity
advantag

high dirt-holding capacity

Buy It Now

Fiberglass Water Treatment Filter

Applications

Widely used in industrial water treatment, circulating cooling water, and RO pre-treatment in industries such as power generation, petrochemicals, steel, electronics, food & beverage, and water treatment.

Large-volume water filtration for municipal water supply & RO pre-treatment.
High-flow filtration for boiler feed water & condensate polishing in power plants.
Sanitary filtration for food & beverage process water systems.
Process water & chemical filtration for petrochemical and refinery applications.

Product Parameter

Parameter Category	Parameter	Typical Value / Range
Dimensions	Outer Diameter	152.4 mm (6 inch)
	Length	20", 40", 60" (80" available for some brands)
	Inner Diameter	Approx. 89 mm (3.5 inch)
Filtration Performance	Filtration Rating	0.5 μm – 100 μm (selectable)
	Flow Rate per Cartridge (40")	Recommended: 50–60 m³/h; Max: 70–80 m³/h
	Filtration Area (40")	Approx. 5.6 – 8.5 m²

product advantages

Filtration efficiency of high-flow filter cartridges refers to the cartridge's ability to remove particulates of a target size under specific operating conditions, typically expressed as a percentage. This efficiency is closely related to the cartridge's micron rating, pore size distribution, filter media structure, and fluid properties.

Fiberglass Water Treatment Filter

High flow capacity

High throughput design, with a single cartridge delivering 30–100 m³/h, substantially reducing the total number of cartridges required

low pressure drop

Graded pore structure enabling depth filtration with high contaminant retention capacity, extending change-out intervals

high dirt-holding capacity

Compact construction for simple, quick installation and minimized maintenance efforts

low operating cost

Versatile material options for filter media and auxiliary components, customizable to specific process conditions

Packaging and Shipping

We provide professional, efficient, and integrated packaging and transportation services for foreign trade clients,

ensuring that goods reach their global destinations safely and on time.

Packaging And Shipping

Packaging

We select export-grade, eco-friendly materials based on cargo characteristics, including reinforced cartons, moisture-proof shrink wrap, wooden pallets, and fumigation-free plywood cases. Each package is clearly marked with product name, quantity, weight, and consignor/consignee details to facilitate identification and customs clearance. We also optimize stowage plans to help reduce freight costs.

Factory introduction

Xinxiang Jun Filters and Chemical Co.,Ltd.

Xinxiang Jun Filters and Chemical Co.,Ltd.is a professional manufacturer engaged in the design and production of filters,filtration equipment, purification devices, and oil-water separation devices.The company has gathered a large number of professional, senior engineers and other technological elites, specializing in design research and development manufacturing.
The R&D team is strong, with a high level of professional technology and rich practical experience. The company has advanced production equipment and a complete quality and safety assurance system.

FAQ

Fiberglass Water Treatment Filter

01.What is the difference between high-flow and standard filter cartridges?

A single high-flow cartridge handles 30–100 m³/h, far exceeding the 1–10 m³/h capacity of standard cartridges. With a 6-inch large-diameter design, high-flow cartridges require fewer units, occupy less space, and simplify replacement and maintenance.

02.How do I determine the right flow rate for my system?

Base your selection on the system design flow and operating hours. We recommend sizing at 70%–80% of the design flow to allow a safety margin for water quality fluctuations and flow decay as the cartridge gradually loads.

03.Is higher filtration precision always better?

Not necessarily. Overly high precision shortens service life and raises operating costs. Choose a rating that satisfies the quality requirements of downstream equipment-no need to pursue the finest grade without cause.

04.Can cartridges from different manufacturers be used interchangeably?

If interface dimensions and seal positions match, physical installation is possible. However, filtration efficiency, pressure drop, and dirt-holding capacity may differ. We recommend conducting on-site tests with samples before switching suppliers in full.

05.How can I extend cartridge service life?

Strengthen upstream pretreatment (e.g., multimedia filtration, coagulation/sedimentation) to reduce influent suspended solids and colloids. Avoid sudden pressure surges during operation. Monitor differential pressure changes regularly and replace on demand rather than running beyond the recommended interval.

06.Besides price, what should I consider when purchasing?

Evaluate media material, structural integrity, seal reliability, factory test reports, batch-to-batch consistency, and after-sales responsiveness. A low price may indicate compromised quality-total cost of ownership matters more than unit price.
